| SYSTEM TYPE | Monochrome Digital Multifunction Imaging System |
| FUNCTIONS | Standard: Copy, Print (UFR II), Scan, Send, Store Optional: Print (PCL 5e/6, Adobe® PostScript® 3™), Fax (Up to 4 Lines) |
| OPERATION PANEL | Standard: 8.4″ SVGA Full-Color, TFT Screen Optional: 10.4″ SVGA Full-Color, TFT Upright Screen |
| MEMORY | Standard: 1.5GB RAM Maximum: 2GB RAM |
| HARD DISK DRIVE | Standard: 160GB Maximum: 1TB |
| MIRRORING HARD DISK DRIVE | Optional (160GB, 1TB), Method: RAID1 |
| NETWORK INTERFACE CONNECTION | Standard: 10Base-T/100Base-TX/1000Base-T Optional: Wireless LAN (IEEE 802.1x via third-party adapter) |
| OTHER INTERFACE | Standard: USB 2.0 (Host) x2, USB 2.0 (Device) Optional: Device Port [USB 2.0 (Host) x2], Serial Interface, Copy Control Interface |
| COPY / PRINT SPEED (BW) | Letter: Up to 55 ppm Legal / 11″ x 17″: Up to 39 / 32 ppm |
| FIRST-COPY-OUT-TIME (LETTER) | 3.3 Seconds or Less |
| PAPER SOURCES (20 lb. Bond) | Standard: Dual 1,500-sheet Paper Drawers, Dual 550-sheet Paper Cassettes, 100-sheet Stack Bypass Optional: 3,500-sheet Paper Deck Unit-A1 or 3,500-sheet Paper Deck Unit-D1 Maximum: 7,700 Sheets (w/Paper Deck Unit Option) |
| OUTPUT PAPER CAPACITY (LTR, 20LB BOND) | Standard: 250 Sheets (w/Copy Tray) Maximum: 4,000 Sheets (w/Staple Finisher or Booklet Finisher) |
| ACCEPTABLE PAPER SIZES | Drawers: Letter Cassettes: 11″ x 17″, Legal, Letter, Letter-R, Executive, Statement-R, Custom Size (5-1/2″ x 7-1/8″ to 11-3/4″ x 19-1/4″) Bypass: 11″ x 17″, Legal, Letter, Letter-R, Executive, Statement-R, Custom Size (4″ x 5-7/8″ to 11-3/4″ x 19-1/4″) |
| ACCEPTABLE PAPER WEIGHTS | Drawers/ Cassettes: 14 lb. Bond to 80 lb. Cover (52 to 220g/m2 ) Bypass: 14 lb. Bond to 140 lb. Index (52 to 256g/m2 ) |
| DUPLEXING | Paper Size: Standard Automatic Trayless Duplexing (Up to 11″ x 17″) Paper Weights:14 lb. Bond to 80 lb. Cover (52 to 220g/m2 ) |
| MEDIA SUPPORT | Thin [14 lb. Bond to 16 lb. Bond (52 to 63g/m2 )], Plain [17 lb. Bond to 24 lb. Bond (64 to 90g/m2)], Heavy 1 [25 lb. Bond to 66 lb. Cover (91 to 180g/m2 )], Heavy 2 [67 lb. Cover to 80 lb. Cover (181 to 220g/m2 )], Heavy 3 [82 lb. Cover to 140 lb. Index (221 to 256g/m2 )], Color, Recycled, Pre-Punched, Transparency, Tracing, Labels, Bond, Letterhead, Tab |
| WARM-UP TIME | From Power On: 30 Seconds or Less From Sleep Mode: 30 Seconds or Less Quick Startup Mode: 7 Seconds* |
| POWER REQUIREMENTS / PLUG | 120-127V AC, 60Hz, 16A/NEMA 5-20P |
| POWER CONSUMPTION | Maximum: 1.92kW Sleep Mode: 0.9W or Less |
| DIMENSIONS (W X D X H) | Without the Upright Control Panel: 48″ x 25-3/8″ x 30-3/8″ (1220mm x 645mm x 770mm) With the Upright Control Panel (To the right edge of the Upright Control Panel in the right-most position): 49-1/4″ x 53-3/8″ x 30-3/8″ (1252mm x 1481mm x 770mm) |
| INSTALLATION SPACE (WXD) | Without the Upright Control Panel: 53-5/8″ x 30-3/8″ (1362mm x 770mm) With the Upright Control Panel: 74-7/8″ x 30-3/8″ (1901mm x 770mm) |
| WEIGHT | Approx. 516 lb. (234kg)** |
